Cisco uyumlu SFP-10G-LR Fiber Modül

Compatible

SFP-10G-LR

Vendor Name

Longline

Form Factor

SFP+

Max. Data Rat5

10.3125Gbps

Wavelength

1310nm

Max. Cable Distance

10km

Connector

Duplex LC

Media

SMF

Transmitter Type

DFB

Receiver Type

PIN

TX Power

-8.2~-0.5dBm

Receiver Sensitivity

< -14.4dBm

Powerbudget

3.8dB

Receiver Overload

0.5dBm

Typical Power Consumption

<1W

Extinction Ratio

>3.4dB

Commercial Temperature Range

0 to 70°C (32 to 158°F)

Protocols

IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI
